Product Introduction

Aluminum coated EPE composite insulation roll is a flexible lightweight composite roll material that integrates reflective insulation and conductive barrier. Its structure is composed of high reflectivity aluminum plated film and ultra-low thermal conductivity EPE (polyethylene) cotton composite through environmentally friendly technology, which is widely used in various scenarios requiring temperature stability, freshness and quality in cold chain logistics.

Features:

1. Efficient insulation: Aluminum plated film has a thermal reflectivity of ≥ 90%, effectively reflecting radiant heat; EPE cotton has an independent closed cell structure with a thermal conductivity of ≤ 0.035 W/(m · K), extremely low thermal conductivity, and blocks heat conduction from the source, effectively reducing temperature fluctuations.

2. Waterproof and moisture-proof; The surface is flat and smooth, with excellent waterproof and oil penetration resistance. In high humidity and dew prone environments, the material itself does not mold or rot, and can be wiped clean immediately.

3. . Green and environmentally friendly: The product has passed ROHS and REACH environmental certifications, is non-toxic, odorless, and non irritating, and can directly come into contact with food packaging

4. Convenient to use: The material is lightweight, with excellent flexibility, and can maintain good folding performance even in low temperature environments of -18 ℃, reducing storage space. Easy to handle, cut, and lay, greatly reducing operational difficulty.

5. Economic durability: The material is tough and can be reused multiple times, reducing the cost of a single purchase. Lightweight design reduces transportation energy consumption and has low overall usage costs, making it an ideal choice for cold chain insulation materials.

MPET Foil Foil EPE Foam Technical Parameters

Test Items (Standards)	5mm	10mm
Thermal Resistance (ASTM-C518-21)	0.143 (㎡·K)/W	0.25 (㎡·K)/W
Thermal Conductivity (ASTM-C518-21)	0.035 W/m·k	0.04 W/(m·k)
Reflectivity (ASTM E424)	95% - 97%
REACH Material Safety (1907/2006)	241SVHC ≤0.1(ND)
ROHS Material Safety (2011/65/EU)	No 31 heavy metals detected
High & Low Temperature Resistance (EN 1604:2013)	-40℃-80℃
Water Vapor Transmission Rate (ASTM E96)	<0.02㎡.h

Resource Download

Note: This product can be tested and customized according to different market standards with reference to varying market demands.
